"ADA Compliance Requirements"
As a commercial property owner or manager it is your obligation to provide adequete parking for the disabled. The American Disabilities Act set forth the requirements to follow in order to comply.
|
# of Provided Parking
Spaces
|
Min. # of Accessible
Parking Spaces (60" &
96" aislies)
|
Min. # of Van
Accessible Parking
Spaces (60" & 96"
aisles)
|
Accessible Parking
Spaces with Min. 60"
wide spaces
|
|
1 to 25
|
1
|
1
|
0
|
|
26 to 50
|
2
|
1
|
1
|
|
51 to 75
|
3
|
1
|
2
|
|
76 to 100
|
4
|
1
|
3
|
|
101 to 150
|
5
|
1
|
4
|
|
151 to 200
|
6
|
1
|
5
|
|
201 to 300
|
7
|
1
|
6
|
|
301 to 400
|
8
|
1
|
7
|
|
401 to 500
|
9
|
2
|
7
|
|
501 to 1000
|
2% of total parking
spaces
|
1/8 of Column A*
|
7/8 of Column A**
|
|
1001 & Over
|
20 plus 1 for each 100
over 1000
|
1/8 of Column A*
|
7/8 of Column A**
|
The following standards apply for ADA parking Compliance:
* one out of every 8 accessible spaces ** 7out of every 8 accessible parking spaces
An example using the above chart is as follows. If your parking lot has 173 parking spaces, your requirements would be to have a total of 6 accessible spaces as follows: 1- Van Accessible (96" wide) & 5- Accessible (60" wide) as noted by the yellow section above.
All Handicap parking areas should provide a non-obstructed accessible route (cross-walk) to the accessible entrance. The cross-walk should be a minimun of 3 feet wide. The slope of asphalt should be no more than 1:12 feet ratio.
All Handicap parking should be located on flat ground. The slope requirement are 1:50 feet for the access adjacent to the parking spaces. The access aisles should always be connected to the cross walk.
This is a brief synopsis of the requirements in which the ADA has set as precedence for parking lot layout. For a detailed analysis for all of your pavement marking &line striping needs please call a representative from Just Stripe It © @ 717-855-7775
Link to ADA site: http://www.ada.gov/restribr.pdf
